| Info | Compatible with |
Product information
Specifications
| Bolt Hole Circle Ø [mm]: | 114,3 |
| Brake Disc Thickness [mm]: | 28 |
| Brake Disc Type: | Vented |
| Fitting Position: | Front Axle |
| Height [mm]: | 47,8 |
| Hole Ø [mm]: | 114,3 |
| Hub Diameter [mm]: | 68,8 |
| Minimum thickness [mm]: | 26 |
| Original number: | 51712-1M500 , 51712-2L500 , 51712-2Y000 , 51712-3K100 , 51712-3K110 , 51712-3K150 , 51712-3K160 , 51712-A6600 , 517120Z000 , 517122Y000 , 517123K100 , 517123K110 , 517123K160 , 51712M0500 , S517120Z000 , S517123K160 , S517123K160A |
| Outer Diameter [mm]: | 300 |
