| Info | Compatible with |
Product information
Specifications
| Bolt Hole Circle Ø [mm]: | 108 |
| Bore Ø [mm]: | 12,8 |
| Brake Disc Thickness [mm]: | 20,4 |
| Brake Disc Type: | Vented |
| Centering Diameter [mm]: | 66 |
| Fitting Position: | Front Axle |
| Height [mm]: | 34,2 |
| Hole Ø [mm]: | 108 |
| Hole-Ø [mm]: | 12,8 |
| Inner Diameter [mm]: | 133,2 |
| Minimum thickness [mm]: | 18,5 |
| Number of bolts/screws: | 247 |
| Number of Holes: | 4 |
| Original number: | 4246 94 , 4246 A7 , 424694 , 4246A7 , 4249 96 , 424996 , 91 517 695 , 91517695 , 95 661 747 , 95661747 |
| Outer Diameter [mm]: | 247 |
