| Info | Compatible with |
Product information
Specifications
| Bolt Hole Circle Ø [mm]: | 100 |
| Bore Ø [mm]: | 15,6 |
| Brake Disc Thickness [mm]: | 25 |
| Brake Disc Type: | Vented |
| Centering Diameter [mm]: | 65 |
| Fitting Position: | Front Axle |
| Height [mm]: | 34,5 |
| Hole Ø [mm]: | 100 |
| Hole-Ø [mm]: | 15,6 |
| Inner Diameter [mm]: | 136 |
| Minimum thickness [mm]: | 22 |
| Number of bolts/screws: | 288 |
| Number of Holes: | 5 |
| Original number: | 1J0 615 301 C , 1J0 615 301 K , 1J0 615 301 R , 1J0 615 301 S , 1J0615301C , 1J0615301K , 1J0615301R , 1J0615301S , 6R0 615 301 A , 6R0 615 301 D , 6R0615301A |
| Outer Diameter [mm]: | 288 |
