| Info | Compatible with |
Product information
Specifications
| Clamp: | B+ (M8) |
| Connecting Angle [Degree]: | +38 |
| Flange Ø [mm]: | 66 , 66,0 |
| Length 1/ Length 2 [mm]: | 230 mm / 0 mm |
| Length 3 [mm]: | 19 |
| Number of Fastening Bores: | 3 |
| Number of mounting bores: | 3 |
| Number of Teeth: | 10 , 10, 11 |
| Original number: | 1108182 , 1108186 , 35605617 , 60 01 040 105 , 6001040105 , 7111509 , 7680406481 , 77 00 864 634 , 7700102800 , 7700106426 , 7700700188 , 7700735712 , 7700761416 , 7700777478 , 7700852853 , 7700853712 , 7700861013 , 7700864634 , 7700866505 , 7701351391 , 7701351392 , 7701351794 , 7701499229 , 7701499477 , 7702146495 , 8111510 , 8200466763 , 8200724823 , 8251642 , 860201983 , 8602083 , MD329260 |
| Quality: | +Line Original |
| Rated Power [kW]: | 1,7 |
| Rotation Direction: | Clockwise rotation |
| Voltage [V]: | 12 |
